Keyboard Test
Test your keyboard on an on-screen US QWERTY layout. Keys light up while you hold them and stay marked once tested. The tool counts the keys you tested and the most keys held at once, which helps you check rollover and spot ghosting.
Key features
- On-screen layout with Esc, F1 to F12, letters, numbers and modifiers
- Instant highlighting of pressed and released keys
- Max Simultaneous counter for the most keys held at once
- Tested keys stay green so you can see which keys never registered
Guide
A keyboard tester shows you which keys your computer receives when you press them. It is the fastest way to check a new keyboard, find a dead key, or see how many keys your keyboard can register at the same time. The WebRecast Keyboard Test does this in your browser with an on-screen layout and three counters.
What the layout covers
The on-screen keyboard has six rows in a US QWERTY arrangement. The top row holds Esc, F1 to F12 and Delete. The number row runs from the backquote key to Backspace. The next rows hold the letters, the brackets, backslash, semicolon, quote, comma, period and slash, plus Tab, Caps Lock, Enter and both Shift keys. The bottom row holds left and right Ctrl, left and right Alt, and the space bar.
The layout does not include arrow keys, the numeric keypad, Insert, Home, End, Page Up, Page Down, Print Screen, Scroll Lock, Pause, the Windows or Command key, or media keys. If the browser receives one of those keys, the Keys Tested counter still goes up, but no key lights up on the screen.
The tool identifies keys by their physical position, not by the character they type. On a German or French keyboard, the key in the Y position of a US keyboard lights up as Y even if it types Z. This is useful for spotting dead switches, but it does not show your local layout.
How the colors work
A key turns bright green while you hold it down. When you release it, it stays light green to show that it has been tested. Keys you have not pressed yet stay gray. The Reset button clears all colors and counters so you can start a fresh test.
The three counters
Currently Pressed shows how many keys you are holding right now. Max Simultaneous shows the highest number of keys you held at the same time during the test. Keys Tested shows how many different keys the browser has received since the last reset. When Max Simultaneous reaches 6 or more, the page shows a short anti-ghosting message.
Checking for dead keys
Press every key once, row by row, from the top left to the bottom right. When you finish, look for gray keys on the layout. A gray key either did not register or was never pressed. Press it again firmly. If it still stays gray, test the same key in a text editor. If it fails there too, the switch, the membrane or the connection is the likely cause.
If a key works with a firm press but not a light one, the switch may be worn or dirty. On mechanical keyboards, cleaning or replacing the switch often fixes it. On laptops, crumbs and liquid under the key are common causes.
Testing rollover and ghosting
Rollover is the number of keys a keyboard can report at the same time. Many basic keyboards report only a few keys at once in certain combinations. Gaming keyboards often report six or more, and some report every key.
To test rollover, hold the keys you use together in games, for example W, A, Shift and Space, and watch the Max Simultaneous counter and the layout. If you hold four keys and only three light up, your keyboard blocked one of them. Try other combinations, because rollover limits often depend on which keys share a circuit inside the keyboard.
Ghosting is the opposite problem: a key lights up that you did not press. Hold common combinations and look for any key that turns green without your input. If that happens, avoid that combination in games or remap the controls.
What the browser can and cannot see
The tool only sees what the browser receives. The Fn key on most laptops and many compact keyboards is handled inside the keyboard and never reaches the browser. Media keys, volume keys and some function keys are often handled by the operating system. Shortcuts such as Alt+Tab, Ctrl+Alt+Delete, Command+Tab or the Windows key may be taken by the system before the page sees them. A key that does not light up because of a system shortcut is not broken.
While the test page is open, the tool blocks the normal browser action of each key, so shortcuts such as Ctrl+F or the space bar scrolling do not interrupt your test. If you switch to another window while holding a key, the browser may miss the key release and the key can stay bright green. Press and release it again to clear it.
Useful moments to run the test
Run it when you unpack a new keyboard, before the return window closes. Run it after you clean a keyboard, swap keycaps or replace switches, to make sure nothing was knocked loose. Run it when a key starts to type twice or not at all, to find out whether the problem is in the keyboard or in a program. For a Bluetooth keyboard paired with a tablet, open the page in the tablet browser and press each key to see which ones the tablet passes through.
Frequently asked questions
Can I test my Fn or Media keys?
Usually not. The Fn key is handled inside most keyboards and never reaches the browser, and the operating system often takes media keys. The layout also has no arrow keys, numpad or Windows key. Keys outside the layout still raise the Keys Tested count if the browser receives them.
How do I know if a key is broken?
Press the key and watch the layout. If it does not light up, try it in a second app or on another computer. If it fails there too, the problem is likely in the keyboard.
